2 Technical specification
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data.
2.1 Electrical connection
230V ~ 50Hz ~ 60Hz
Milling spindle motor power 750 W
2.2 Milling capacity
Drilling capacity in steel (S235JR) [mm] Ø 16
Drilling capacity in steel (S235JR) [mm] Ø 12
Max. milling head size [ mm] Ø 52
Max. end mill cutter size [ mm] Ø 20
2.3 Spindle seat
Spindle seat MT2
Drawbar M10
Maximum distance between spindle nose - milling table
[mm]
255
2.4 Drill-mill head
Spindle sleeve stroke [mm] 50
Quill diameter [mm] 60
Manual travel Z axis [mm] 210
Throat [mm] 170
Inclination range ± 90°
