Optimum Optimill MH 20V - Page 46

Version 2.5.1 - 2020-7-2846 Original operating instructions
TU1503V | TU2004V | TU2304V |
GB
Adjusting_control-board_BA-integrated_GB.fm
Measuring range min. 1 M Ohm
Potentiometer
Setting value
Only approximate value,
perform setting via
speed control
.
Measuring points
measuring point 3
+ 12V
measuring point 1
measuring point 2
measuring point 4
