Version 1.1.0 - 2020-08-07 77Translation of original instruction
MH35G│MH35V EN
MH35G_MH35V_GB_7.fm
7 Malfunctions
7.1 Milling machine malfunctions
Malfunction
Cause/
possible effects
Solution
Tool "burnt". • Incorrect speed.
• Chips are not coming out of the
drilled hole.
• Blunt tool.
• Operating without cooling agent.
• Choose a different speed, exces-
sive feed.
• Withdraw the tool more frequently.
• Sharpen or replace tool.
• Use coolant.
Taper cannot be inserted in
quill.
• Remove any dirt, grease or oil
from the internal conical surface of
the spindle sleeve or the taper.
• Screwed pull stud?
• Clean surfaces well.
Keep surfaces free from grease.
•
Pull stud on page 19
Motor does not start. • Defective fuse.
• Circuit breaker
• Have it checked by qualified per-
sonnel.
Rattle the spindle if the
workpiece surface is rough.
• Upcut mill machining not possible
under the current operating condi-
tions.
• Clamping lever of the movement
axes not tightened.
• Loose collet chuck, loose drill
chuck, mechanical security tool
clamping system not engaged.
• Tool is blunt.
• The workpiece is not fastened.
• Excessive slack in bearing.
• Spindle moves up and down.
• Perform conventional milling.
• Tighten the clamping lever.
• Check, enable mechanical security
tool clamping system.
• Sharpen or renew the tool.
• Clamp the workpiece firmly.
• Readjust the bearing slack or
replace the bearing.
• Readjust the bearing slack or
replace the bearing.
Fine feed of the spindle
sleeve does not work
• Fine feed is not correctly activated.
• Coupling of the fine feed does not
cam-in, is soiled, blurred, worn,
defective
•
Spindle quill feed on page 36
• Clean, replace.
Earth leakage circuit breaker
trips
• EMC filter in the frequency con-
verter. Not correct type of RCCB in
MH35V
• When the ELCB triggers on
page 31
