SETUP AND INSTALLATION
14 English
Wall Mounting
Use only an Optoma-approved optional wall mount kit (available separately). Kit will include the following items:
Screw A (x4)
Screw B (x8)
Screw C (x2)
Dual mounting brackets and wall mount
Anchor (x8)
Washer (x8)
e
Wall Mount Specifications
Model Name
VESA Grid
Screw Type & Length
65-inch
600 x 400 mm
M8*25L
75-inch
800 x 400 mm
M8*25L
86-inch
800 x 600 mm
M8*25L
65-inch 75-inch
86-inch
