Optoma 3 Series User Manual

SETUP AND INSTALLATION
18 English
A
Stand Mounting (Optional)
The stand mount kit includes the following items:
Pen tray (x1)
Wheel (x4)
Screw J (x16)
Screw H (x4)
Nut G (x4)
Washer G1 (x4)
Split Ring Lock
Washer G2 (x4)
Stand pole (x2)
Stand base (x1)
Screw K (x4)
Washer K1 (x4)
Nut K2 (x4)
To mount the IFP on the stand, complete the following steps:
1. Install the dual mounting brackets on the rear of the IFP. Then secure the brackets with four
screws (A).
Note: Dual mounting brackets, wall mount, and screws (A) are included in the wall mount kit. Refer to
“Wall Mounting” on page 14.
