Optoma DC554 - Step 3; Connecting with Components

11
Step3/ConnectingwithComponents
Product
Port
Cable
Display
Device Port
PC Port
VGA
RGB OUT-
PUT
RGB INPUT
RGB
INPUT
RGB
OUTPUT
HDMI
HDMI
OUT
HDMI-INPUT
HDMI
IN
HDMI-
OUTPUT
USB
TYPE B
Port
TYPE A Port TYPE A Port
• Connect via VGA OUTPUT
DC 5V
USB
VGA OUT
HDMI OUT
To display images, you can use VGA cable to connect to your television’s RGB
port via the VGA OUT connector.
