Optoma EP721 - Page 52

52
English
Appendices
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX73 n 7E 30 30 37 33 20 n Signal Frequency n= -50 - +50
~XX74 n 7E 30 30 37 34 20 n Phase n= 0 - +31
~XX75 n 7E 30 30 37 35 20 n H. Position n= -50 - +50
~XX76 n 7E 30 30 37 36 20 n V. Position n= -50 - +50
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX77 n 7E 30 30 37 37 20 n Security Security Timer Month/Day/Hour nnnnnn
~XX78 1 7E 30 30 37 38 20 31 Security Settings On
~XX78 2 7E 30 30 37 38 20 32 Off
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX79 n 7E 30 30 37 39 20 n Projector ID n=00-99
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX80 1 7E 30 30 38 30 20 31 Mute On On
~XX80 2 7E 30 30 38 30 20 32 Off Off
~XX81 n 7E 30 30 38 31 20 n Volume n=0-15
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX82 1 7E 30 30 38 32 20 31 Start Up Logo On
~XX82 2 7E 30 30 38 32 20 32 Off
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX100 1 7E 30 30 31 30 30 20 31 Source Lock On
~XX100 2 7E 30 30 31 30 30 20 32 Off
~XX101 1 7E 30 30 31 30 31 20 31 High Altitude On
~XX101 2 7E 30 30 31 30 31 20 32 Off
~XX102 1 7E 30 30 31 30 32 20 31 Information Hide On
~XX102 2 7E 30 30 31 30 32 20 32 Off
~XX103 1 7E 30 30 31 30 33 20 31 Keypad Lock On
~XX103 2 7E 30 30 31 30 33 20 32 Off
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX104 1 7E 30 30 31 30 34 20 31 Background Colour Blue
~XX104 2 7E 30 30 31 30 34 20 32 Black
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX105 1 7E 30 30 31 30 35 20 31 Advanced Direct Power On On
~XX105 2 7E 30 30 31 30 35 20 32 Off
~XX106 n 7E 30 30 31 30 36 20 n Auto Power Off (min) n=0-180
~XX107 n 7E 30 30 31 30 37 20 n Sleep Timer (min) n=0-999
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX108 1 7E 30 30 31 30 38 20 31 Lamp Setting Lamp Hour
~XX109 1 7E 30 30 31 30 39 20 31 Lamp Reminder On
~XX109 2 7E 30 30 31 30 39 20 32 Off
~XX110 1 7E 30 30 31 31 30 20 31 Brightness Mode Bright
~XX110 2 7E 30 30 31 31 30 20 32 STD
~XX111 1 7E 30 30 31 31 31 20 31 Lamp Reset Yes
~XX111 2 7E 30 30 31 31 31 20 32 No
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX112 1 7E 30 30 31 31 32 20 31 Reset Yes
~XX112 2 7E 30 30 31 31 32 20 32 No
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX121 1 7E 30 30 31 32 31 20 31 Input Source
~XX122 1 7E 30 30 31 32 32 20 31 Software Version
~XX123 1 7E 30 30 31 32 33 20 31 Display Mode
~XX124 1 7E 30 30 31 32 34 20 31 Power State
~XX125 1 7E 30 30 31 32 35 20 31 Brightness
~XX126 1 7E 30 30 31 32 36 20 31 Contrast
~XX127 1 7E 30 30 31 32 37 20 31 Aspect Ratio
~XX128 1 7E 30 30 31 32 38 20 31 Colour Temperature
~XX129 1 7E 30 30 31 32 39 20 31 Projection Mode
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to Remote
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX140 1 7E 30 30 31 34 30 20 31 Power
~XX140 3 7E 30 30 31 34 30 20 33 Remote Mouse Up
~XX140 4 7E 30 30 31 34 30 20 34 Remote Mouse Left
~XX140 5 7E 30 30 31 34 30 20 35 Remote Mouse Enter
~XX140 6 7E 30 30 31 34 30 20 36 Remote Mouse Right
~XX140 7 7E 30 30 31 34 30 20 37 Remote Mouse Down
~XX140 8 7E 30 30 31 34 30 20 38 Mouse Left Click
~XX140 9 7E 30 30 31 34 30 20 39 Mouse Right Click
~XX140 10 7E 30 30 31 34 30 20 31 30 Up/Page +
~XX140 11 7E 30 30 31 34 30 20 31 31 Left/Source
~XX140 12 7E 30 30 31 34 30 20 31 32 Enter (for projection MENU)
~XX140 13 7E 30 30 31 34 30 20 31 33 Right/Re-SYNC
~XX140 14 7E 30 30 31 34 30 20 31 34 Down/Page -
~XX140 15 7E 30 30 31 34 30 20 31 35 Keystone +
~XX140 16 7E 30 30 31 34 30 20 31 36 Keystone -
~XX140 17 7E 30 30 31 34 30 20 31 37 Volume -
~XX140 18 7E 30 30 31 34 30 20 31 38 Volume +
~XX140 19 7E 30 30 31 34 30 20 31 39 Brightness
~XX140 20 7E 30 30 31 34 30 20 32 30 Menu
~XX140 21 7E 30 30 31 34 30 20 32 31 Zoom
~XX140 22 7E 30 30 31 34 30 20 32 32 DVI
~XX140 23 7E 30 30 31 34 30 20 32 33 Freeze
~XX140 24 7E 30 30 31 34 30 20 32 34 AV Mute
~XX140 25 7E 30 30 31 34 30 20 32 35 S-Video
~XX140 26 7E 30 30 31 34 30 20 32 36 VGA
~XX140 27 7E 30 30 31 34 30 20 32 37 Video
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when standby/warming/cooling/out of range INFOn n : 0/1/2/3 = Standby / Warming / Cooling /
Out of Range
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX150 1 7E 30 30 31 35 30 20 31 Information OKabbbbcdddde a: 1/0=On/Off
bbbb: LampHour
c: source 0/1/2/3/4/5/6= None/DVI-D/VGA1/
VGA2/SCART/S-Video/Video
dddd: FW version
e: Ddisplay mode
~XX151 1 7E 30 30 31 35 31 20 31 Model name OKn n: 0/1/2/3 EP721 / EP723 / EP727 / EP728
