English
49
Appendices
Lamp Replacing Procedure:
1. Switch off the power to the projector by pressing the Power button.
2. Allow the projector to cool down at least 30 minutes.
3. Disconnect the power cord.
4. Unlock the lamp cover.
5. Push up and remove the cover.
6. Use a screwdriver to remove the screw from the lamp module.
7. Pull out the lamp module.
To replace the lamp module, reverse the previous steps.
8. Turn on the projector and do “Lamp Reset” after the lamp module is
replaced.
Lamp Reset: (i)Press “Menu” -> (ii)Select “System” -> (iii)Select “Lamp
Settings” ->(iv)Select “Lamp Reset” -> (v)Select “Yes”.
2
4
3
1
