AMR650
Frequency Response 60Hz - 20kHz (+/- 2dB)
THD <0.25% @ 5W, 1kHz
Signal/Noise ratio > 80dB
Input impedance (local input) 33K Ohms
Volume control range 0 to -78dB in 31 steps
Pre-amp output Variable, following volume setting
IR passthrough 34-40kHz and 54-58kHz
frequencies supported
Speaker impedance 4 Ohms
Power requirement +24V DC @ 1A max from hub
Weight (AMR650-A) 1.4kg / 3.1lbs
Weight (AMR650-P) 1.1kg / 2.4lbs
Dimensions 240 x 75 mm, 9.4 x 3 inches
20
WCU300 EU version CU version
Frequency response 20Hz–20Hz
Volume control range - 80dB 32 steps
Bass control range +/- 16dB 2dB steps
Treble control range +/- 16dB 2dB steps
Balance control range +/- 40dB 9 steps both ways
IR pass-through 34–40kHz and 54–58kHz modulation
Required power input Powered from MCU300 via Cat-5 cable
System specifications continued
