SRC300
Battery 2 AA/LR6 alkaline batteries
Dimensions (W x H x D) 43 x 18 x 182mm (approx)
Weight 112g (inc batteries)
LRC300
Battery 4 AAA/LR03 alkaline batteries
Dimensions (W x H x D) 65 x 25 x 190mm (approx)
Weight 200g (inc batteries)
PSA65U
Input 100-240V AC 50/60Hz
Output 24V DC @ 2.5A
Efficiency 80%
Line/load regulation 5%
Approvals UL, CE, T Mark, TUV, FCC Class B, EN 55022B,
EN 5008-1 1997, EN 61000-4-2/3/4/5/6, Level 2,
EN 61000-4-11
C39
Coupler length 39mm
21
OS165CC
Frequency response 58Hz–20Hz +/- 3dB
Sensitivity 90dB SPL @ 1 watt/1 metre
Nominal impedance 4 Ohms
Power handling 15–80 watts
Enclosure type In-ceiling infinite baffle
Drive components 1 x 1.3cm tweeter, 1 x 16.5cm woofer
Crossover frequency 4.5kHz
Mounting depth required (min) 75mm
Cutout dimensions 207mm
Recommended back air 22 litres
or volume
Weight 1.5kg
