Oracle Acme Packet 1100 Hardware Installation And Maintenance Guide

3
System Installation
This chapter provides information about how to install the Acme Packet 1100 and its associated
components, includes cabling information.
Shipped Parts
Each Acme Packet 1100 ships in one box. Inside this box is the Acme Packet 1100 chassis and
the accessory kit.
The following table lists the contents of one Acme Packet 1100 order.
Table 3-1 Acme Packet 1100 Shipping Contents
Location Item
Main Shipping Box Acme Packet 1100 chassis
Accessory Kit • AC power cords
• AC power supply
Options - Flanges for Rack Mounting
- Brackets for Wall Mounting
Installation Tools and Parts
The following tools and parts are required to install the Acme Packet 1100 into your equipment
rack:
• #2 Phillips-head screwdriver
• Rack and associated mounting hardware
• Shielded Ethernet CAT5e or CAT6 RJ45 cables
• RS-232CF cable with RJ45 jack (SER MGT port)
• Cable with RJ48C jack (T1/E1 port)
Recommended Tools and Parts
Oracle recommends that you have the following parts on hand:
• Cable labels
• UPS for AC installations
• ESD wrist or heel straps
• ESD-safe location
3-1
