Remove Air Duct
160 Oracle Database Appliance Service Manual • June 2017
Removing and Installing the Air Duct (FRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The air duct for the Oracle Database Appliance Version 1 must be removed to service the CPUs.
The air duct is a FRU and can only be replaced by an Oracle-qualified service technician.
Caution - Equipment overheating. Ensure that the air duct is installed correctly before
powering on the server.
This section includes the following topics:
■
“Remove Air Duct” on page 160
■
“Install Air Duct” on page 161
Remove Air Duct
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the air duct from Oracle Database Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 112.
b.
Remove the server node from the system.
See “Removing Server Nodes From the System Chassis” on page 113.
Power is removed from the server node when you remove it from the system.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 114.
