Servicing the ZS3-2 Controller
Figure Legend
1 Air Filter 5 Drive power cable (FRU) 9 Fan modules
2 Drives 6 Drive signal cable (FRU) 10 Fan tray
3 Chassis (FRU) 7 Top cover 11 USB board (FRU)
4 LED board (FRU) 8 PDB signal cable (FRU) 12 Power supplies
ZS3-2 Internal Cables
The ZS3-2 controller contains the following field-replaceable unit (FRU) internal cables. FRUs
are not customer-serviceable, and must be replaced by trained Oracle service technicians.
FIGURE 28
ZS3-2 Controller Internal Cables
118 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
