2-14
INSTALLATION ORBAN Model 6200
JFJE
JAJB
JC
TOP OF MAIN BOARD
JA JA
*
CLIPPER ON CLIPPER OFF
JE JF
LEFT
OUTPUT
RIGHT
OUTPUT
JE JF
LEFT
OUTPUT
RIGHT
OUTPUT
*
FLAT PRE-EMPHASIZED
JB JC
LEFT
OUTPUT
RIGHT
OUTPUT
JB JC
LEFT
OUTPUT
RIGHT
OUTPUT
*PEAK AVG
Clipper Jumpers
Output Pre-Emphasis Jumpers
Line-up Level Jumpers
Figure 2-5: 8200ST Jumper Settings (*Factory Configuration)
