TECHNICAL MANUAL BLUE PAPER ORDU · OMX 20212 | ORBEA ORBEA | 3
EN
01 INTRODUCTION 04
Key to symbols
02 ORBEA WARRANTY 06
03 MAINTENANCE 08
Keep your bicycle clean
Keep your drivetrain lubricated
Inspect your bicycle before every ride
Maintenance schedule
Replacement parts
After a crash or an impact
04 USE WARNINGS 11
Maximum tyre width
Seatpost and front post minimum insertion
Intended use
ORDU OMX 2021 12
05 GEOMETRY AND SIZING 14
06 TECHNICAL SPECIFICATIONS 16
07 ASSEMBLY AND SPARES 19
HEADSET AND STEM
Head tube measurements
*GCFUGVURGEKƂECVKQPU
Headset and stem assembly and spares
Headset adjustment
AXLES AND REAR DERAILLEUR HANGER
Trainer compatibility
Speed release axles use
CHAINSTAYS AND BOTTOM BRACKET
SEATPOST
HANDLEBAR
Base handlebar
Bridge and extensions
AERO BOTTLE AND TOOLBOX
08 CABLE ROUTING 35
CABLE ROUTING. MECHANICAL ASSEMBLIES
Brake hoses
Gears
CABLE ROUTING. ELECTRONIC ASSEMBLIES
Brake hoses
Shimano DI2 system
Blipbox junction (Sram Etap)
09 ADJUSTMENT OF FITTING ELEMENTS 42
Front post height adjustment
Extensions position adjustment
Saddle position and angle adjustment
Bridge and extensions angle adjustment
Bridge orientation adjustment
Base handlebar height change
10 DECLARATION OF CONFORMITY 54
11 ADDITIONAL INFORMATION 55
ORDU OMX DEALER ASSEMBLY GUIDE (ES|EN|FR|DE) 110
INDEX EN P.02 | ES P.56
