Box 1 is labeled with the ColdBlock image.This box contains the AirSTAR
ColdBlock and a european power plug.
Box 2 is labeled with the CFPP or CPPP Head image.This box contains all
parts of the AirSTAR CFPP or CPPP Head. This box also contains the power
adapter and tray for the Cleaning-Docking station.
Box 3 is labeled with the Cleaning-Docking station image.This box contains
the Cleaning-Docking station and cleaning beaker.
1.2 ASSEMBLY COLDBLOCK
IMPORTANT:
Before switching on ColdBlock, remove the 4 black clamps from the bottom
of the unit. (During transport these clamps fix the inside cooling engine to the
unit’s body. When in operation, the cooling engine should be free from the
unit’s body to prevent vibration).
How to remove the clamps:
• carefully tilt ColdBlock a little bit sideways.
• remove the bolt that holds the clamp (wrench size 8). Remove the clamp.
(image 1 & 2)
• repeat on the other side.
• carefully lift and turn ColdBlock in operation position (front side with iPad
facing you)
