INSTALLATION
Security warnings
The following instructions must be observed during installation and operation of
equipment:
The equipment must be installed by authorized and qualified
personnel who comply with the instructions of this manual.
The equipment must be installed and activated in compliance
with the current low voltage regulations.
Do not use the equipment for purposes other than that
specified.
Before installing the smart charger, check that it is not
damaged.
Before accessing the connecting terminals, verify that the
cables are not under electric voltage. The opening of the
enclosure does not imply the absence of tension within it. It may
only be opened by authorized and qualified personnel.
In accordance with the applicable regulations, the installer
should check whether overvoltage protection measures are
necessary.
Use only the specified charging cable for each electric vehicle.
In no case should another type of extension cable be used.
In case of malfunction, do not perform repairs and contact our
Technical Services immediately.
After installation, inaccessibility to connecting terminals without
appropriate tools should be ensured.
Ensure appropriate tools are always used.
To protect the intelligent charger against potential vehicle
impacts, the installation of a protective barrier is recommended.
If your charger has an outlet with a connection cable, cover the
connector with its supplied rubber cover to prevent the entry of
Assembly requirements
The minimum installation height of the power outlets and
connectors should be 0.6 m above ground level. If the charger
is intended for public use, the maximum height shall be 1.2 m
and in places for persons with reduced mobility, between 0.7 m
and 1.2 m. (See the instructions of the country where the
installation is carried out in case other heights are specified).
The mounting plate must be located at a height between 0.4 m
and 1.5 m above ground level.
The charger must be installed upright and allow clearance for
maintenance.
Use seals or presses to ensure the level of IP protection of the
