FINISH INSTALLATION
 Connect ribbon cable from charger to input on front panel (as shown below)
ensuring it is firmly connected.
To remove the front panel, carefully disconnect
the cable by pressing the eyelashes as indicated
by the arrows.
 Secure the front panel to the installation base and secure with screws.

 Click the finishing frame firmly into place.
Wall
Mounting
Plate
Installation Base
Front Panel
Finishing
Frame
