⑫Seat(Seat slide and Seat suspension functions Equipped.)
Adjust the seat slide front and back by raising the slider lever in front of Seat. The suspension
can be adjustable the strength of the spring force according to the weight of the worker using
the "suspension adjustment bolt" on the front of the seat in the left photo. Turning it
clockwise will make it stronger, and turning it counterclockwise will make it weaker. After
starting the engine, the engine will stop for safety if you leave the seat when the cutting
height adjustment lever is not in the “move” position and the parking brake pedal is not in
the “lock” position (the pilot light will not go out and the engine switch is keep to (RUN)
state).
If the engine stops, immediately turn off the engine switch. Or Re start the engine.
If the engine is stopping for a while, the battery will run down.。
〈4.1
Refer to How to start and stop the engine
〉
⑬Handle tilt lock lever
The angle of the handle position can be adjusted according to the physique of the worker.
Loosening the lock lever and tighten it at any position to lock it. The lever will be free when
pulled up. After deciding the steering wheel angle, you can fix it at the desired position.
Do not operate the handle tilt while driving as it is dangerous.
⑭Fuse box
Protects the harness and electrical components in case of overcurrent. There are 10A
(accessory) and 20A (charge) fuses, and a separate 20A fuse is included as a spare. If the
fuse blows, remove the cause and replace it with a spare fuse. also, use the spare fuse only
for emergencies and immediately replace it with a regular A (ampere) fuse.
⑮inclinometer
When working on a sloping ground, the pointer on a simple inclinometer indicates a reference
angle for the location. If you want to measure the angle more accurately, use a handheld
type angle meter.
Suspension adjust bolt
Seat Slide Lever
