Mechanical Timber Harvesting Handbook
8
Lubrication
Your cutting systems operates in challenging environments and
depend on sufficient lubrication to minimize wear and extend the
life of operation.
Both bar and chain oils and grease can provide adequate
lubrication to the cutting system when used correctly.
When using grease, ideal settings can vary based on temperature
and other work-site conditions. Always begin by consulting your
manufacturer’s recommendations.
Regular inspection of your cutting system will let you know if any
adjustments are needed.
• Both hydraulic fluid and used motor oil are not approved
lubricants and their use can the warranty of your cutting
system.
• Hydraulic fluid does not provide sufficient properties for
preventing wear of your cutting system.
• Used oils may contain acidic compounds and abrasive
particles that can compromise the cutting system's
effectiveness and increase wear.
Operational Recommendations
Technical Data (Metric Units)
Oregon Saw Chain Part Number
.404" Pitch 3/4" Pitch
18HX 19HX 11BC 11H
Operating Parameters
Guide bar/Saw chain oil
mL/cut 3 3 10 10
Power, at saw motor kW min/max 5/50 15/50 5/65 5/75
Force on guide bar to tension
saw chain, N
490 490 668 668
Guide Bar Feed Load, at Center, N
Min/max 100/900 100/900 100/1300 100/1300
Recommended 700 700 900 900
Saw Chain Speed, m/sec
Min/max 15/40 15/40 10/35 10/35
Recommended 40 40 30 30
