Saw Chain
41 Mechanical Timber Harvesting Handbook
Saw Chain Repair
3. Cutter and tie-strap replacement parts should be filed back to
match the existing chassis parts as shown below.
4. Place the preset tie-strap on a flat outer surface of a breaker
anvil with the rivets pointing up.
5. Assemble the saw chain to the preset tie-strap.
6. Assemble the tie-strap with brand mark or dot face up and the
notch toward the drive link tangs.
18HX 18HX 18HX 18HX
18HX 18HX 18HX 18HX
OREGON OREGON OREGON OREGON
OREGON OREGONOREGONOREGON
