Orgapack CR 25 A - English; 1 Technical Data; Npt); Db (A)

05.07/WE
17
ORGAPACK CR 25 A
1 TECHNICAL DATA
TABLE OF CONTENTS
Weight 3.2 kg (7 lbs)
Dimensions Length 302 mm (17.75“)
Width 130 mm (5“)
Height 180 mm (7“)
Tension force Up to approx. 3000 N
Tension speed 75 mm/s (3“/s)
Air pressure Maximum 6 bar static
Air consumption
– Tensioning 4 Nl/s
– Sealing 3.4 Nl
Air connection G
1
/
4
“ (
1
/
4
“ NPT)
Sealing Sealjoint with 1 notch
Emission sound pressure
levels, measurement
type A (EN ISO 11202) L
pA
83 dB (A)
Vibrations at handle
(EN ISO 8662-1) a
h,w
< 2,5 ms
-2
STEEL STRAP
Strap width 13, 16, 19 mm
(
1
/
2
“,
5
/
8
“,
3
/
4
“)
Normal quality:
Strap thickness 0.40–0.63 mm (.015“–.024“)
Tensile strength Up to approx. 850 N/mm
2
(117‘000 lbs/in
2
)
High strength
quality:
Strap thickness 0.40–0.63 mm (.015“–.024“)
Tensile strength Up to approx. 1100 N/mm
2
(156‘000 lbs/in
2
)
SEALS
Strap width 13 mm CSP 411
Strap width 16 mm CSP 511
Strap width 19 mm CSP 611
Page
1 Technical data 17
2 General information 18
2.1 Information on environmental protection 18
3 Safety instructions 19
4 Description 20
4.1 Design 20
4.2 Function 20
5 Initial operation 21
5.1 Suspending the tool 21
5.2 Compressed-air connection 21
6 Operating instructions 22
6.1 Operating the tool 22
7 Preventive and corrective maintenance 24
7.1 Adjusting tensioning force/tensioning speed 24
7.2 Setting clearance between tension wheel and
tension plug 24
7.3 Replacing tension wheel 24
7.4 Replacing cutting knife 25
7.5 Replacing jaws and notcher 25
7.6 Cleaning the tool 25
8 Parts list 26
Explosion drawing 28
9 Parts list compressed air motor 29
Explosion drawing 30
We take sole responsibility for declaring that the
tool CR 25 A, to which this declaration refers, is in
full compliance with the current requirements of the
guidelines laid down by the council on 22th June
1998 (98/37/EEC), “Machine Guidelines“.
According to norm:
EN ISO 12100-1, EN ISO 12100-2, EN 349,
EN 983, EN 1050 prEN 792-2
CH-8953 Dietikon, February 2002
Manager Manager
Sales & Marketing: Engineering:
R. Kieffer M. Binder
DECLARATION OF AGREEMENT
