ORGAPACK CR 25 A

6.1 OPERATING THE TOOL

– Draw the strap from the dispenser, slide the strap

through the seal (4/1) and wind strap around the

package.

– Push the strap start a second time through the seal.

– Bend the strap start (5/1) below the seal 3–4 cm

(1–2“).

– Pull the strap tightly by hand and take a portion of

the strap leading to the dispenser with the left hand

approx. 20 cm (8“) away from the seal.

– Hold the handle (6/1) of the tool in the right hand

and raise the motor up to the stop.

– Insert the strap below the tension wheel completely

into strap guide. At the same time push the tool

forward against the seal.

– Release the motor.

6 OPERATING INSTUCTIONS

Fig. 4

Fig. 5

Fig. 6
