Orgapack CR 25 A - 8 Parts List; Explosion Drawing

26
05.07/WE
ORGAPACK CR 25 A
1 1174.200.115 Cylinder 1
2
3
4
5 1174.200.114 Cylinder cover 1
6
7
8 1820.100.036 Valve stem, long 1
9 1820.100.030 Sleeve 2
10 1820.100.033 Ring 1
11 1820.100.034 Sleeve 1
12 1927.601.020 O-Ring, ø 10 x 2 4
13 1927.601.600 O-Ring, ø 16.1 6
14 1820.010.208 Compression spring 1
15
16 1820.100.035 Valve stem, short 1
17 1820.100.031 Sleeve 1
18 1820.100.032 Sleeve 1
19 1925.010.802 Ball 1
20 1820.010.047 Compression spring conical 1
21 1927.600.420 O-Ring, ø 4 x 2 1
22
23 1174.200.120 Piston 1
24 1928.011.050 Piston ring, ø 105 1
25 1927.600.610 O-Ring, ø 6 x 1,5 1
26 1820.020.261 Washer 2
27 1916.306.062 Lock washer, M 6 1
28 1927.601.010 O-Ring, ø 10 x 1,5 1
29 1174.200.137 Gasket 1
30
31
32 1174.200.131 Slider 1
33 1820.030.413 Bolt 1
34 1174.200.128 Link 2
35
* 36 1174.200.141 Jaw 13 mm 2
* 36 1174.200.142 Jaw 16 mm 2
* 36 1174.200.143 Jaw 19 mm 2
37
38 1174.200.125 Notcher 13 mm 2
38 1174.200.126 Notcher 16 mm 2
38 1174.200.127 Notcher 19 mm 2
39
40 1174.200.132 Plate 1
41 1174.200.133 Front plate 13 mm 1
41 1174.200.134 Front plate 16 mm 1
41 1174.200.135 Front plate 19 mm 1
42
43
44 1820.020.262 Bushing 1
45 1820.020.263 Bushing 2
When ordering please indicate part number and quantity Explosion drawing see page 28
* Recommended spare parts
Pos. Part no Part name Quantity
8 PARTS LIST 1174.200.100/11
Pos. Part no Part name Quantity
46 1820.030.415 Bolt 2
47 1820.030.414 Bolt 2
48 1820.030.412 Special screw, M 6 2
49 1911.905.252 Counter sunk screw, M 5 x 25 1
50 1916.305.052 Lock nut, M 5 1
51 1
52
* 53 1174.200.152 Cutter complete 13 mm 1
* 53 1174.200.124 Cutter complete 16, 19 mm 1
54
55
56
57 1174.200.121 Cutter guide 1
58 1921.305.120 Straight pin, ø 5m6 x 12 2
59 1820.010.207 Compression spring 1
60
61
62
63 1174.200.150 Base plate complete,
incl. pos. 64-67 13 mm 1
63 1174.200.148 Base plate complete,
incl. pos. 64-67 16 mm 1
63 1174.200.149 Base plate complete,
incl. pos. 64-67 19 mm 1
64
65 1921.304.120 Straight pin, ø 4m6 x 12 13 mm 2
65 1921.304.100 Straight pin, ø 4m6 x 10 16 mm 2
65 1921.304.080 Straight pin, ø 4m6 x 8 19 mm 2
* 66 1174.200.146 Strap guide 13 mm 1
* 66 1174.200.147 Strap guide 16 mm 1
* 66 1174.200.145 Strap guide 19 mm 1
* 67 1921.902.085 Roll pin, ø 2,5 x 8 2
68
69
70 1820.040.101 Tension plug 1
71 1910.104.088 Set screw, M 4 x 8 1
72
73 1820.030.416 Special screw, M 6 1
74 1820.030.417 Special screw, M 6 1
75
76
77 1174.200.116 Gear housing complete 1
78 1935.510.100 Slide bearing, ø 10/12 x 10 2
79
80
81
82 1820.030.410 Axe 1
* 83 1820.010.209 Torque spring 1
84 1921.804.122 Roll pin, ø 4 x 12 1
85
86 1933.908.080 Needle bearing, ø 8/12 x 8 1
