05.07/WE
27
ORGAPACK CR 25 A
Pos. Part no Part name Quantity
Pos. Part no Part name Quantity
87 1933.815.120 Needle bushing, ø 15/21 x 12 1
88 1928.615.213 Gasket, ø 15/21 x 3 1
89 1820.030.411 Tension shaft 1
90 1173.200.063 Key 2
91 1820.060.082 Worm gear 1
92 1820.060.081 Worm gear wheel 1
* 93 1820.040.100 Tension wheel 1
94
95
96 1934.310.150 Thrust bearing, ø 15 2
97 1934.430.150 Counter washer, ø 15/28 x 0,8 2
98 1934.015.120 Needle bushing, ø 15/21 x 12 2
99
100
101 1174.200.118 Cover, left 1
102
103
104 1174.200.111 Cover, right 1
105
106
107 1174.200.139 Lever, yellow 1
108 1174.200.140 Lever, green 1
109 1174.200.138 Bolt 1
110 1820.030.418 Special screw, M 4 1
* 111 1820.010.211 Torque spring 1
* 112 1820.010.210 Torque spring 1
113
114
115 1174.200.117 Handle 1
116
117
118
119
120
121 1940.070.723 One-way restrictor, G 1/4” 1
122
123
124
125
126
127
128 1173.400.044 Air hose 1
129 1941.210.720 Gasket, G 1/4” 5
130 1941.111.040 Hose connection, G 1/4” 2
131 1941.112.720 l-Connection, G 1/4” 1
132 1940.331.188 Hose clamp, ø 18 2
133
134
135
136 1934.310.100 Thrust bearing, ø 10 1
137 1934.430.100 Counter washer, ø 10/22 x 0,8 1
138
139
140 1174.200.157 Suspension bow 1
141 1940.311.721 Air plug, G 1/4” 1
142
Pos. Part no Part name Quantity
143
144
145
146
147 1911.005.208 Cylinder screw, M 5 x 20 2
148 1911.005.168 Cylinder screw, M 5 x 16 10
149 1919.605.062 Lock washer, M 5 13
150 1911.005.128 Cylinder screw, M 5 x 12 1
151 1911.005.258 Cylinder screw, M 5 x 25 1
152
153 1911.272.127 Locking screw, G 1/4” 1
154
155 1820.090.068 Oil lable 1
156
157
158 1894.332.000 Air motor, Type LZB22 A008-50 1
159 1174.200.136 Key 1
160
161
162
163 1174.200.162 Cover 1
164
165
166 1820.090.198 Name tag 1
167 1820.090.172 Label “Made in Switzerland“ 1
Variation USA/CAN
141 1820.100.019 Air connector, 1/4“ NPT 1
177 1820.100.017 Transition connection,
G 1/4“-1/4“ NPT 1
Variation with device to fi x the lever
168 1174.200.155 Handle 1
* 169 1820.010.010 Compression spring 1
Variation with air connection on motor
128 1173.400.044 Air hose 1
129 1941.210.720 Gasket, G 1/4“ 2
130 1941.111.040 Hose connection, G 1/4“ 2
132 1940.331.188 Hose clamp, ø 18 2
175 1174.200.154 Connection angle 1
