05.07/WE

ORGAPACK CR 25 A

1 1894.332.011 End plate 1

2 1894.332.010 Gear housing (Rear side) 1

3 1894.332.013 Silencer 1

4 1894.332.033 Mesh screen 1

5 1894.332.002 Ball bearing 1

6 1894.332.003 Bearing plate rear 1

7 1894.332.001 Pin 2

8 1894.332.005 Cylinder 1

9 1894.332.004 Rotor 1

10 1894.332.007 Blade 5

12 1894.332.009 Bearing plate front 1

13 1894.332.008 Ball bearing 1

15 1894.332.014 Ball bearing 4

16 1894.332.015 Shaft 2

17 1894.332.016 Bearing needle 2

18 1894.332.017 Planetary wheel 2

19 1894.332.019 Planetary cage 1

20 1894.332.020 Threaded bushing 1

21 1894.332.021 Saucer spring 2

22 1894.332.022 Shaft 2

23 1894.332.024 Bearing needle 24

24 1894.332.023 Planetary wheel 2

25 1894.332.026 Planetary cage 1

26 1894.332.029 Gear housing (Front side) 1

27 1894.432.020 Gasket 1

28 1894.332.028 Front part 1

When ordering please indicate part number and quantity Explosion drawing see page 30

9 PARTS LIST COMPRESSED AIR MOTOR 1894.332.000/2

Pos. Part no Part name Quantity
