19
02.04/WE
ORGAPACK OR-T 200
5 INITIAL OPERATION
5.1 BATTERY CHARGER
The mains supply must comply with the specifications
on the rating plate (Fig. 5).
The battery charger is suitable only for charging
batteries from the Bosch range of tools (NiCd/NiMH)
with voltages between 7.2 V and 14.4 V.
5.2 FIRST BATTERY CHARGE
Please observe the following points in order to
ensure optimum battery life:
– Connect battery charger (6/2) to mains supply.
– Insert battery (6/1) into battery charger slot.
For the first charge, leave the battery in the
charger for at least five hours, regardless of the
battery indicator. (The charging time for all subse-
quent charges is about 60 minutes)
For all subsequent charges, only recharge the
battery when the LED indicator on the tool indi-
cates battery empty (see Chapter 6.3). Avoid
charging when the battery is not yet discharged.
This will ensure optimum battery capacity and life.
Maximum battery output will be reached after four or
five charging/discharging cycles.
5.3 CHARGING THE BATTERY
The charging process and error functions are indicated
by a green light (6/3) (see chapter 4.4).
The charging time is approximately 60 minutes.
The maximum charging current flows when the tem-
perature of the battery is between 15–45°C. Avoid
charging the battery at temperatures below 0° C.
If the battery is not to be used for a longer
period (several days), it should be removed
from the tool and charged/stored in the battery charger.
The intelligent charger with fuzzy control charges the
battery with the optimum rapid charging current, de-
pending on temperature and capacity. If fully charged, a
preserving charge will prevent self-discharge and thus
guarantee a long battery life.
Fig. 5
Input 230 V 50/60 Hz / 44 W
Output 7.2-14.4 V 1.9 A
Fig. 6
1
2
3
