Orgapack OR-T 55 - Table of Contents

0623 IH-10933VND
2 of 20
V 02.22_EN
ORGAPACK OR-T 55
1 General information 3
2 Safety 4
2.1 General safety warnings for power tools 4
2.2 Use for the intended purpose 6
2.3 Working safely 6
2.4 Safety instructions 6
3 Description 8
3.1 Design 8
3.2 Function 9
3.3 Scope of delivery 9
4 Preparing for operation and settings 10
4.1 Battery 10
4.2 Setting strap tension 11
4.3 Setting welding time 11
5 Operating instructions 12
5.1 Strapping 12
5.2 Checking the seal 14
5.3 Setting the strap width 15
6 Preventive and corrective maintenance 16
6.1 Preventive maintenance schedule 16
6.2 Cleaning the tool 16
6.3 Replacing the tension wheel 16
6.4 Replacing the tension shoe 17
6.5 Troubleshooting 18
7 Technical data 19
8 EC Declaration of Conformity (copy) 20
Table of contents
Translation of original manual according to „Machine Directive“ 2006/42/EEC.
Read the operating instructions carefully.
These operating instructions are part of the product and therefore should be kept for later use or a
future owner.
Validity
● OR-T 55 from Series no E/21111001
Manufacturer
Orgapack
c/o Signode Switzerland GmbH
Silbernstrasse 14, Postfach
8953 Dietikon 1
SWITZERLAND
orgapack.com
H -1 0933
