ORGAPACK OR-T 55
5 Operating instructions
5.1 Strapping
Preconditions
● The tool is adjusted to the width of the strap to be used (Section 5.3).
● The charged battery is inserted (Section 4.1.2).
● Desired maximum tension force is set (Section 4.2).
● Desired welding time is set (Section 4.3).
► Place the strap around the package and hold
it with the left hand so that the lower strap
lead is approx. 20 cm (8“) away from the
hand.
► Take the tool with the right hand and press the
tensioning lever towards the handle.
► Slide the strap start under the tension shoe (2)
and below the cutting device (1) into the tool
until the stop is reached.
– The lower strap is now approx. 5 cm (2“)
beyond the tool.
► Release the lever.
► Insert the strap from dispenser between the
tension wheel (3) and the tension shoe (2).
Then insert the strap into the slot of the cutting
device (1) until stop is reached.





20 cm
