9
9. Place mattress firmly on top of sensor pads. When using with a slat
based cot, ensure the sensor pads are stable & supported adequately.
If the mattress cannot be in direct contact with the sensor pads, or if
the cot base is soft or padded, place plywood (not supplied) on the cot
base, place the sensor pads on the plywood and place the mattress
firmly on top to enable full contact of the sensor pads with the
mattress.
IMPORTANT WARNING: To avoid possible danger of strangulation
from cords, keep the cords out of reach of children. Ensure that
excess cords are secured with the included cable tie.
Layout of control unit
See illustration 8 for layout of control unit featuring:
• On/Off button.
• Blue movement indicator light.
• Acoustic and visual red alarm light.
• Low battery red warning light.
Movement
indicator light
Red alert
alarm light
Low battery
warning light
On/Off
button
I
llustration 8
Speaker
