Reciever
Circuit Type Dual conversion superheterodyne
IF Frequencies 1st IF = 30.85MHz, 2nd IF = 450kHz
Current Consumption during RX 170mA
Sensitivity < -123dBm for 12dB SINAD
Sensitivity Receive only channels < -110dBM for 12dB SINAD
Selectivity +/-3.75kHz min @ 3dB to +/-15kHz
max @ 40dB
Intermodulation Immunity > 70dB
Spurious Immunity > 70dB
Audio Output Power 3 Watts Maximum
RX Audio Signal de-emphasis -6dB per octave 300Hz to 3 kHz
Audio frequency response 300Hz to 3kHz
Dimensions Transceiver 150 (d) x 180 (w) x 50 (h)
mm (DIN Car Radio size)
Weight approx 900g
23
UHF088 Technical Specication
