Oricom UHF300 - Microphone and Display

7
Controls and Connectors
Microphone (Part No. MIC300)
8. RJ45 microphone plug
9. Microphone rubber boot
10. Push To Talk (PTT) button
11. Volume down
12. INS and CALL
13. Volume up
14. Condensor mic.
LCD Icons & Indicators
15
16
1819
17
15. Menu functiuon display
16. Memory indicator
17. Channel, Volume and
squelch level indicator
18. DPX indicator
19. Signal and power level
indicator
