Oriental motor BMU Series User Manual

Specications
−46−
14 Specications

Specications
The value in a state where the gearhead is not combined is described in each specication for the "rated torque,"
"instantaneous peak torque," "rated rotation speed" and "speed control range."
Refer to the operating manual of the motor for the motor model name.
Model
Motor
BLM5200HP
BLM5200
BLM6200SHP
BLM6200S
BLM7200HW
BLM5300HP
BLM5300
BLM6300SHP
BLM6300S
BLM7300HW
BLM5400HP
BLM5400
BLM6400SHP
BLM6400S
BLM7400HW
Driver
BMUD200-A BMUD200-C BMUD300-C BMUD400-S
Rated output power
(Continuous)
200 W 300 W 400 W
Power
supply
input
Rated voltage Single-phase 100-120 V
Single-phase 200-240 V
Three-phase 200-240 V
Single-phase 200-240 V
Three-phase 200-240 V
Three-phase 200-240 V
Permissible
voltage range
−15 to +10%
Rated
frequency
50/60 Hz
Permissible
frequency
range
±5%
Rated input
current
4.6 A
Single-phase: 2.7 A
Three-phase: 1.5 A
Single-phase: 3.4 A
Three-phase: 2.1 A
2.8 A
Maximum
input current
9.3 A
Single-phase: 4.9 A
Three-phase: 3.4 A
Single-phase: 7.8 A
Three-phase: 4.7 A
5.1 A
Rated torque 0.637 N·m (90 oz-in) 0.955 N·m (135 oz-in) 1.27 N·m (180 oz-in)
Instantaneous peak torque 1.15 N·m (163 oz-in) 1.43 N·m (200 oz-in) 1.91 N·m (270 oz-in)
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*
*
There are products, which maximum rotation speed is 3600 r/min, depending on the gearhead type.
Check the operating manual of the motor.

General specications
Operation
environment
Ambient temperature 0 to +40 °C [+32 to +104 °F] (non-freezing)
*
Ambient Humidity 85% or less (non-condensing)
Altitude Up to 1000 m (3300 ft.) above sea level
Surrounding atmosphere
No corrosive gas or dust.
Cannot be used in radioactive materials, magnetic eld, vacuum or other
special environment.
Details about the installation location are described on p.9.
Vibration
Not subject to continuous vibrations or excessive impact
In conformance with JIS C 60068-2-6 "Sine-wave vibration test method"
Frequency range: 10 to 55 Hz
Pulsating amplitude: 0.15 mm (0.006 in.)
Sweep direction: 3 directions (X, Y, Z)
Number of sweeps: 20 times
Storage
environment
Shipping
environment
Ambient temperature Driver: −25 to +70 °C [−13 to +158 °F] (non-freezing)
Ambient Humidity 85% or less (non-condensing)
Altitude Up to 3000 m (10000 ft.) above sea level
Surrounding atmosphere
No corrosive gas, dust, water or oil.
Cannot be used in radioactive materials, magnetic eld, vacuum or other
special environment.
Degree of protection Driver: IP20
*
When the 300 W or 400 W type driver is installed with the front panel side facing upward: 0 to +35 °C (+32 to +95 °F)
