To Next PageTo Next PageWhat causes the timing output to fail in an Oriental motor CRK?
If the timing output is not being output on your Oriental motor Engine, it may be because the C/S (step angle switching) input is switched to “ON” when timing output is not being output. Switch the C/S input to “ON” when timing output is being output.
What to do if the Oriental motor CRK Engine is too hot?
If the Oriental motor Engine is overheating, there are a few potential causes. The motor may be experiencing long continuous operation, in which case you should decrease the operation time per session or increase the standstill time. Also, check if the C.D.INH input is set to ON and switch it to OFF. Finally, the motor standstill current adjustment might be too high; adjust it to 50% of the operating current or below.
What to do if the Oriental motor CRK Engine does not run?
If the Oriental motor Engine does not run, check the pulse input line connection between the controller and driver. Also, the current potentiometer might be incorrectly set; return it to its factory setting and check. If the CW and CCW inputs are ON simultaneously, input either the CW or CCW input, and switch the other terminal to OFF.
Why is the Oriental motor CRK Engine vibration too great?
Excessive vibration in the Oriental motor Engine can be caused by a few things. Check the connection condition of the motor’s output shaft and load shaft to ensure they are aligned. If the vibration decreases when the operating pulse speed is changed, it could be due to motor resonating. Also, if the load is too small, try lowering the motor operating current.
What to do if the Oriental motor CRK is not energized?
If the Oriental motor Engine is not energized, first, check for connection errors in the motor leads or power supply cable between the driver, motor, and power supply. If the current potentiometer is incorrectly set, return it to its factory setting and check. Also, verify that the A.W.OFF input is set to OFF to ensure the motor is excited.
Why is Oriental motor CRK Engine rotating in the opposite direction?
If an Oriental motor Engine rotates in the opposite direction, the CW and CCW inputs may be connected in reverse. Connect the CW pulses to the CW input (pins No. 1 and 2), and connect the CCW pulses to the CCW input (pins No. 3 and 4).
Why is my Oriental motor Engine too hot?
If an Oriental motor Engine is too hot, it could be due to several reasons. First, reduce the motor's continuous operation time or increase the standstill time, ensuring the motor case temperature does not exceed 100 °C (212 °F). Second, verify the current cutback release input is set to “OFF.” Third, adjust the motor’s standstill current to one-half of the operating current or below.
What to do if Oriental motor Engine does not move the set amount?
If the Oriental motor Engine does not move the set amount, first check the C/S input switching state. Then, verify the settings of the step angle setting switches [DATA1] and [DATA2]. Finally, ensure that the correct number of pulses for the set step angle are being output.
What to do if the Oriental motor CRK TIMING output is not output?
If the Oriental motor Engine TIMING output is not output, switch the C/S input when TIMING output is ON.
Why is the Oriental motor CRK driver too hot?
If the Oriental motor Engine driver is too hot, it may be due to long continuous operation of the motor. Decrease the operation time of the motor per session or increase the standstill time.
Covers motor and driver installation methods, location, and EMC compliance.
Details wiring procedures for motor, driver, I/O signals, and grounding.
Explains different motor operation types and timing charts.
Provides a comprehensive list of memory addresses for operation data and parameters.
Covers troubleshooting communication errors, alarms, and warnings in RS-485.
Details how to control the driver using CC-Link communication with a network converter.
Explains control using MECHATROLINK communication with a network converter.
Explains driver alarms, warnings, their causes, and remedial actions.
Provides guidance on diagnosing and fixing operational problems and motor behavior issues.
General| Brand | Oriental motor |
|---|---|
| Model | CRK Series |
| Category | Engine |
| Language | English |
