ADJUSTING INTELLI Q
Boost Levels 0dB +3dB +6dB +10dB
Enclosure Type :
Infinite Baffle Acceptable, No High X-Max Not Recommended Not Recommended
Problems. Tune above Drivers. Tune above
Fs of woofer. Fs of woofer.
Sealed Acceptable, No Acceptable, No High X-Max Drivers. Not Recommended
Problems. Tune above Problems. Tune above Tune above Fs
Fs of woofer. Fs of woofer. of woofer.
Vented Acceptable No Acceptable No Acceptable No High X-Max Drivers.
Problems. Tune to Problems. Tune to Problems. Tune to Tune to port frequency.
Port frequency. Port frequency. Port frequency.
Sealed Bandpass Acceptable No Acceptable No High X-Max Drivers Not Recommended
Problems. Tune above Problems. Tune above Drivers. Tune above
Fs ofwoofer. Fs ofwoofer. Fs ofwoofer.
Vented Bandpass Acceptable No Acceptable No Acceptable No High X-Max Driver.
Problems. Tune to Problems. Tune to Problems. Tune to Tune to
port frequency. port frequency. port frequency. port frequency.
Aperiodic Set crossover to Fs Set crossover to Fs Set crossover to Fs Not Recommended
of woofer. of woofer. of woofer.
page 38
