Orion 250R & 275R - Crossover and General Dimensions

input sensitivity
3
200 mV to 5 Vrms 200 mV to 5 Vrms 200 mV to 5 Vrms
input impedance 47kΩ 47kΩ 47kΩ
fuse type (2) 20 AMP ATC (2) 30 AMP ATC (6) 30 AMP ATC
CROSSOVER
SECTION
low-pass crossover
4
Continuously Continuously Continuously
variable variable variable
low-pass frequency range 45Hz to 5kHz 45Hz to 5kHz 45Hz to 5kHz
high-pass crossover Continuously Continuously Continuously
variable variable variable
high-pass frequency range 10Hz to 1kHz, 10Hz to 1kHz, 10Hz to 1kHz,
100Hz to 10kHz 100Hz to 10kHz 100Hz to 10kHz
INTELLi Q boost range 0dB to 10dB 0dB to 10dB 0dB to 10dB
GENERAL 12" x 10.25" x 2.25" 18" x 10.25" x 2.25" 25" x 10.25" x 2.25"
(L x W x H) 305mm x 457mm x 635mm x
260mm x 57mm 260mm x 57mm 260mm x 57mm
(L x W x H) (L x W x H) (L x W x H)
page 9
