© 2008 directed electronics—all rights reserved 13
SPECIFICATIONS
Amplifi er Section CO5001 CO8001
Power Output in Watts RMS, 4 Ohms 175 x 1 300 x 1
Power Output in Watts RMS, 2 Ohms 250 x 1 400 x1
Externally Bridgeable yes yes
Remote Gain Function yes yes
Distortion at Rated Power < 0.9% THD+N < 0.9% THD+N
Frequency Response 20Hz to 30kHz
+0, -1dB
20Hz to 30kHz
+0, -1dB
Linear Bandwidth 20Hz to 20kHz
±3dB
20Hz to 20kHz
±3dB
Damping Factor > 150 > 150
Input Sensitivity rms rms
Input Impedance 80k 80k
Fuse Type (2) 20 Amp ATC (2) 30 Amp ATC
Dimensions 11.4" x 8.1" x 2.1" 13.4" x 8.1" x 2.1"
Weight 6.3 lbs. 7.3 lbs.
Crossover Section
Low Pass Crossover Continuously variable/
2nd Order
Continuously variable/
2nd Order
Low Pass Frequency Range 50Hz to 500Hz 50Hz to 500Hz
Continuous 2 load 20Hz to 200Hz, < 0.1% THD, with input voltage at 13.8VDC.
