Machine Manual Orion
Flex Stretchwrapper Revision 3.0
Troubleshooting 15 February 2016
Page 4-6
Carriage Lift
(Up & Down)
Carriage Will Not Move Up Or
Down (In Either Manual Mode
Or During An Auto Wrap
Cycle)
Carriage Speeds set below 5%.
Check the numerical value of the carriage
up and down speeds on the touchscreen.
Password may be required depending on
the Security Settings.
Increase the carriage up and down speeds
on the touchscreen to above 5%.
Carriage Travel limit strikers set
improperly.
Check the physical positions of the travel
limit strikers.
1. Set the Up Travel limit striker to the
highest wrapping requirement position
within the machine's capability or a jam
may occur.
2. Position the Bottom travel striker to the
lowest wrapping requirement level within
the machine's capability or a false Belt
Error may occur.
Lift Belt Error (Visible obstruc-
tion) has occurred.
Check for a physical obstruction in the
carriage toward travel path and Lift Belt
Error shown on the touchscreen.
If there is an actual obstruction, refer to
the "Carriage Obstacle Detect Error
Recovery" inset in your manual.
VFD parameter settings are
incorrect.
Review the parameter settings in the VFD.
Refer to the supplied VFD Manual for
procedure.
Refer to the VFD manual and the Orion
parameter settings sheet supplied with the
machine for maximum frequency settings.
Table 4-1. Troubleshooting Chart (Continued)
PROBLEM POSSIBLE CAUSE SOLUTION
