Orion RKS250F1-S User Manual

30
Troubleshooting
Alarm Types and Product Response Chart
Alarm Types and Product Response Chart
■Alarm list
Alarm
Number
Name
Actions in
response to
alarms
Operation
Signal
Alarm
Signal
Display Restore
C00
500-hour filter use caution alarm
Running
○ ×
Alternate
dis
p
la
y
s
Manual
E01
Compressor overcurrent relay(RKS400F1)
All stopped
× ○
Alternate
displays
Manual Compressor overload protector(RKS400F1)
Compressor motor protector(RKS250F1-S)
E02
High pressure switch
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
E04
Compressor intake temperature sensor
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
C07
Liquid temperature limit alarm
Running
○ ○
Alternate
dis
p
la
y
s
Auto
C08
Compressor stop less than 3 minutes
Running
○ ×
Alternate
dis
p
la
y
s
Auto
E09 Power phase loss(RKS400F1)
All stopped
× ○
Blinking
Power-on
E10 Power phase reversal(RKS400F1)
All stopped
× ○
Blinking
Power-on
E11
Liquid temperature sensor failure
(measured temperature low)
All stopped
× ○
Blinking
Manual
E12
Liquid temperature sensor failure
(measured temperature high)
All stopped
× ○
Blinking
Manual
E13 Memory error
All stopped
× ○
Blinking
Power-on
E14
Power suspension recovery
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
E15 Other error
All stopped
× ○
Blinking
Manual
E21
Intake temperature sensor abnormal
(measured low temperature abnormal)
All stopped
× ○
Alternate
displays
Manual
E22
Intake temperature sensor abnormal
(measured high temperature abnormal)
All stopped
× ○
Alternate
displays
Manual
※
The symbol ○ indicates is output signal, and the symbol × indicates is not output signal.
※
Operation and alarm signals will be indicated for each occurrence of each alarm.
※
If an error condition occurs such that the operation signal is continuously output, and if another error
also occurs that would shut down the compressor, then the operation signal will be cut off even if the
initial error continues.
※"Alternate display" in the Display column indicates that the water temperature measurement and the
alarm numbers are displayed in turn. "Blinking” indicates that the relevant alarm number blinks.

※
E14 only outputs a signal when the parameter F1 is set to "0" (the default setting.)

