Orion RKS250F1-S - Machine Layout

7
（Front）
Control plate
Drain port

M10
（
Drain plug
）
Water inlet

Rp3/4
Power cord access hole φ30
(incl. grommet)
（Back）
Condenser filter and condenser
Machine Layout
External Appearance
External Appearance
■
External view
Water outlet

Rp3/4
Pump-priming port
(Pump-priming port cap)
Specification plate
