48
Installation
Wiring Work
Distribution box
Power supply terminal section
Signal output
terminal
10,11,12,13
Remote control
terminal
14,15
Ground
RKS250F1-S
RKS400F1
Remote control
terminal
14,15
Signal output
terminal
10,11,12,13
Ground
