Understanding Idle Fuel Feed Rate and Smoke Settings
Smoke Control The Smoke Control switch sets the fuel feed rate (the
Switch amount of fuel delivered in a given period of time) when the
grill is operating in Smoke Mode and when the grill is idling
in Cook Mode.
During cook idle or smoke mode, the auger turns on,
delivers fuel for 15 seconds, then turns off. The off time is
set by the Smoke Control switch.
“P” Settings The fuel feed rate setting is displayed momentarily
whenever the Cook Control switch is set to the Smoke
position. It is also displayed whenever the Smoke Control
switch is adjusted. The setting is designated with the letter
“P” and a number. The greater the “P” setting number the
greater the auger off time.
Setting Auger On Auger Off
P 0 15 seconds 45 seconds
P 1 15 55
P 2 15 65
P 3 15 75
P 4 15 85
P 5 15 95
P 6 15 105
P 7 15 115
P 8 15 125
P 9 15 135
P10 15 140
P11 15 145
P12 15 150
P13 15 155
P14 15 160
P15 15 165
Dual Function The selected “P” setting controls both the Smoke Mode fuel
feed rate and the Cook Mode Idle Fuel Feed Rate. They are
one and the same.
For example, if “P3” is selected using the Smoke Control
switch, the auger delivers fuel for 15 seconds, turns off for
75 seconds, and repeats in Smoke Mode. It also delivers
fuel for 15 seconds, turns off for 75 seconds and repeats
while idling at or above the selected set temperature in Cook
Mode.
