4
Disconnect the If you are removing a Traeger Digital Control, you must
Temperature disconnect the temperature detector. Turn the control until
Detector the circuit board is facing you. Using a small slotted
screwdriver, disconnect the temperature detector lead wires
from the two-terminal connector J1 located in the upper
right hand corner of the printed circuit board.
Remove the If you are replacing a Traeger Digital Control, the
Temperature temperature detector is compatible with the RealTemp
Detector TR-100. Replacing it is optional. For best results, we do
recommend replacing the temperature detector, especially
when installing the TR-100 as a service replacement.
Open the cook lid and remove the internal grill and drip pan.
Locate the temperature detector. Using a medium Phillips
screwdriver, loosen its mounting screw and nut. Lift the
detector and feed its wire leads up and out of the grill.
Temperature
Detector
