OSEE T5+ - Chapter 4 Features; Rear Panel Connectors and Functions

Features
13
Chapter 4 Features
4.1 Parts and Functions
The parts of T5+ is shown as below, there are various input and output
interfaces for T5+ monitor, as shown in Figure 4.1-1.
Figure 4.1-1 Parts in Rear Panel
No.
Connector
Description
1
Power
Switch
Switch to
“
|
”
position to power on; and switch to
“

”
position to power off
