Battery charger for the PUMA T2 hand-held radio
Technical Manual
General information and safety recommendations
P/N: 779-0357/02
Revision 04
OTE Proprietary Information
Page 7
1.4 TECHNICAL CHARACTERISTICS
The main technical characteristics relative to each type of battery charger are
shown in tabb. 1.3÷1.7.
In tab. 1.8 there are shown the mean charging time, of each type of batteries,
relative to the BCU2-1500, BCU2-1500B, BCP2-850 and BCP6-850 models; those
relative to the BCU6-750 model in tab. 1.9 are reported.
Tab. 1.3: BCU2-1500 technical characteristics
Description Value
Power supply voltage: 230 Vac ± 10%
Protecion fuse: Delayed 250 V, (see the equipment
plate for the max current )
Operating temperature:
+10°C ÷ +40°C
NiCd & NiMH Li-Ion
Fast charging current: 1000 ± 50 mA 1500 ± 50 mA
Constant current phase end voltage: / 8.35 ± 0.05 V
Cut-off current: / 170 ± 10 mA
Slow charging current: 230 ± 30 mA
(avg value)
/
Maintenance current: 70 ± 20 mA /
Discharging current: 300 ± 50 mA /
Fast charging interruption threshold voltage: 10.8 ± 0.5 V /
Class: I (EN 60950 IV
th
edition)
Dimensions (length x width x height): 200 mm x 173 mm x 87 mm
Weight: 1850 g
