Battery charger for the PUMA T2 hand-held radio
Technical Manual
Troubleshooting
Page 44 OTE Proprietary Information
P/N: 779-0357/02
Revision 04
The troubleshooting procedures are shown in the flow diagrams whose symbols
are described in tab. 6.2.
Tab. 6.2: Description of the symbols used in the troubleshooting flow diagrams
Symbol Meaning
Stands for the beginning or the end of the flow diagram. The symptom
of the possible fault is described inside the symbol.
Stands for the action to be carried out. This action is described inside
the symbol itself.
Stands for a decision to be made. The question that must be answered
is shown inside the symbol.
Stands for the term of the search.
