OTE BCP2-850 - Fig. 4.1: Battery Charger Positioning; Fig. 4.2: Power Supply Voltage Value Selection for BCU2-1500;B and BCU6-750

Battery charger for the PUMA T2 hand-held radio
Technical Manual
Installation
Page 36 OTE Proprietary Information
P/N: 779-0357/02
Revision 04
1. Battery charger body
2. Mains supply plug
3. Plane surface
Fig. 4.1: Battery charger positioning
1. Mains supply plug
2. Voltage selection switch 230 V / 115 V
Fig. 4.2: Power supply voltage value selection for BCU2-1500/B and BCU6-750
2 1
1
2
Mains
supply
3
