oticon ALFA - Replacing T-Cap Microphone Filter (Instruments with Size 10 Batteries)

2 1
T_Cab_TOOL
T_Cap_microphone cover
38 39
1. Remove the tool from its packaging. The tool has two ends, one for removal of the
T-Cap (A) and one with the new T-Cap (B).
2. Using the removal end, push it under the top edge of the used T-Cap.
3. Lift the used T-Cap up and out.
4. Using the other end of the tool, insert the new T-Cap into the opening and slightly
twist the tool so that the new T-Cap is free.
5. Throw out the tool.
Replacing T-Cap microphone lter
(Instruments with size 10 batteries)
A
B
T-Cap
Handle
4
1 2
3 5
