General Information
2.2 DS5, DS5X Multiprobe
The DS5 and DS5X are designed for in-situ and flow-through applications, and can
measure up to 15 parameters simultaneously. The DS5 and DS5X have seven
configurable ports that can include up to ten of the following sensors: ambient light,
ammonia, chloride, chlorophyll a, rhodamine WT, conductivity, depth, dissolved oxygen,
nitrate, ORP, pH, temperature, total dissolved gas, turbidity, and blue-green algae.
Figure 1 DS5 Multiprobe
Figure 2 DS5X Multiprobe
2.3 MS5 Multiprobe
The MS5 is a portable instrument used for long-term monitoring or profiling applications.
The MS5 has four configurable ports that can include a combination of the following
sensors: ammonia, chloride, chlorophyll a, rhodamine WT, conductivity, depth, dissolved
1. Calibration Cup 5. Bulkhead Connector
2. Storage Cup 6. Battery Compartment (optional)
3. Locking Screw 7. Bail Attachment
4. Housing
1. Calibration Cup 5. Bulkhead Connector
2. Storage Cup 6. Battery Compartment (optional)
3. Locking Screw 7. Bail Attachment
4. Housing
1
6
7
∅
∅
88 mm
3.45 inches
571 mm (22.5 inches)
23
4
5
1
6
7
∅
∅
88 mm
3.45 inches
571 mm (22.5 inches)
23
4
5
