29
Press the <SET> soft key to open the PV Trigger’s TIME
and VOLT(age) set menus.
To adjust the voltage, press the <VOLT> soft key.
Adjust the voltage within a range of 20V-145V by
pressing the < - > or < + > soft key. When  nished,
press the <BACK> soft key to return to the PV Trigger
screen
To adjust the minimum amount of time the PV voltage
must remain high before deactivating the AUX MODE,
press the <TIME> soft key.
AUX MODE
PV Trigger
Output: On On
EXIT NEXT SET MODE
PV VOLTS
>140
BACK - +
AUX MODE
PV Trigger
EXIT TIME VOLT
AUX MODE
PV Trigger
EXIT TIME VOLT
